48V200Ah Stackable LiFePO4 Battery for Solar Power System with RS485/CAN Communication and LCD Indicators

Name: 48V200Ah Stackable LiFePO4 Battery for Solar Power System with RS485/CAN Communication and LCD Indicators
Brand: Shenzhen Bely Energy Technology Co., Ltd.
SKU: BLY-LPF-48V200AH
Price: 562.00 USD
Availability: InStock

Markenbezeichnung:	BeLYEnergy
Modellnummer:	BLY-LPF-48V200AH
MOQ:	10 PCS
Preis:	Verhandelbar
Lieferzeit:	2 bis 3 Wochen für Proben; 4 bis 6 Wochen für die Massenproduktion
Zahlungsbedingungen:	T/T, L/C, Western Union, MoneyGram

Einzelheiten

Produkt-Beschreibung

Einzelheiten

Herkunftsort:

in China hergestellt

Zertifizierung:

CE,ROHS,MSDS,UN38.3

Dimension:

L620x W430 x H430mm oder maßgeschneiderte Größe

Material:

Metallblech

Gewicht:

≤ 105 kg

Zyklus-Lebenszeit:

Mehr als 6000 Zyklen

Nennkapazität:

200 Ah

Anwendung:

Energiespeicherung im Haushalt

Maximaler Entladungsstrom:

200A

Verpackung Informationen:

UN-Karton

Versorgungsmaterial-Fähigkeit:

1000 Stück pro Monat

Hervorheben:

LCD Indicators Stackable LiFePO4 Battery

RS485 Stackable LiFePO4 Battery

48V200Ah Stackable LiFePO4 Battery

Produkt-Beschreibung

Stackable LiFePO4 Battery --48V200Ah 16S With RS485/CAN Communication With LCD Indicators

48V200Ah Stackable LiFePO4 Battery for Solar Power System with RS485/CAN Communication and LCD Indicators 0

BeLY Stackable & Wall Mount Battery is available in capacities of 5kWh, 10kWh, 15kWh and 20kWh etc., which allow you to store

sufficient solar energy to power your home, significantly reduce dependence on the grid and keep home appliance normal running

when the grid goes down.

1. General Information

This specification defines the performance of rechargeable LiFePO4 Stackable home solar storage battery pack BLY-LFP48V100AH manufactured by SHENZHEN BELY ENERGY TECHNOLOGY CO.,LTD, describes the type, performance, technical characteristics, warning and caution of the battery pack.

48V200Ah Stackable LiFePO4 Battery for Solar Power System with RS485/CAN Communication and LCD Indicators 1

2. Battery Specification(@ 25±5℃)

ELECTRICAL SPECIFICATIONS
Nominal Voltage	51.2V
Nominal Capacity	200Ah
Energy	10240Wh
Resistance	≤ 10mΩ
Efficiency	≥ 99%
Self Discharge	＜3% per Month
MECHANICAL SPECIFICATIONS
Dimensions (L x W x H)	L620x W430x H430mm or customized size
Weight	104KG
Terminal Type	M8 Terminal
Case Material	Metal sheet Case
Enclosure Protection	IP20
Cell Type	New Grade A Automotive Prismatic Cells
Chemistry	LiFePO4
CHARGE SPECIFICATIONS
Recommended Charge Current	≤ 200A
Maximum Charge Current	200A
DISCHARGE SPECIFICATIONS
Maximum Continuous Discharge Current	200A
Peak Discharge Current	210A (5S)
Under Voltage Protection	40V
Over Charge Voltage Protection	58.4V
Short Circuit Protection	400 ≤ 500uS
Cells Balancing Voltage	3.5V (Voltage Difference 20mV between each Cells)
TEMPERATURE SPECIFICATIONS
Discharge Temperature	-20 to 60℃
Charge Temperature	0 to 60℃
Storage Tempearture	-10 to 45℃
COMPLIANCE SPECIFICATIONS
Certifications	CE, ROHS, MSDS, UN38.3, DGM, BQB (Battery), UL(Cells)
Shipping Classification	UN3480, CLASS 9
Package	UN Carton

3.Description of LiFePO4 Battery

Lithium - lron - Phosphate (LiFePO4) battery offers a higher charge/discharge cycles, about 6,000 cycles at 100% DOD (depth of discharge). LiFePO4 cathode is intrinsically safer than the LiCo02 or the manganese cathode. We provides a complete line of 12, 24 and 48 volt batteries for use in RV' s, boats, EV' s and off-grid applications and much more. Our wide variety of standard and high performance batteries ensure we have what you need, when you need it.

4. Period of Warranty

The period of warranty is 5 years from the date of shipment. BeLY guarantees to give a replacement in case of battery with defects proven due to manufacturing process instead of the customer abuse and misuse.

5. Application Scenario

48V200Ah Stackable LiFePO4 Battery for Solar Power System with RS485/CAN Communication and LCD Indicators 2

48V200Ah Stackable LiFePO4 Battery for Solar Power System with RS485/CAN Communication and LCD Indicators 3
